Aircraft Extension

Triumph Aircraft Extension Drill Bits are 6" long and ideal for drilling in harder to reach places.  Made of high speed steel with a black oxide finish, these bits can withstand high heat and pressure and will better resist corrosion.  135 degree split point helps reduce walking and scarring for straighter, more precise penetration.

Triumph Twist Drill Aircraft Extension

  Point: 135° Split Point
  Material: High Speed Steel
  Coating/Finish: Black Oxide
  Other: Heavy-Duty Construction

6" Aircraft Extension - Fractional Sizes

SizeDecimal EquivalentFlute LengthOverall LengthPkg QtyPart#
1/16 0.0625 7/8 6 6 057504
5/64 0.0781 1 6 6 057505
3/32 0.0938 1-1/4 6 6 057506
7/64 0.1094 1-1/2 6 6 057507
1/8 0.125 1-5/8 6 1 057708
1/8 0.125 1-5/8 6 6 057508
9/64 0.1406 1-3/4 6 6 057509
5/32 0.1562 2 6 6 057510
11/64 0.1719 2-1/8 6 6 057511
3/16 0.1875 2-5/16 6 1 057712
3/16 0.1875 2-5/16 6 6 057512
13/64 0.2031 2-7/16 6 6 057513
7/32 0.2188 2-1/2 6 6 057514
15/64 0.2344 2-5/8 6 6 057515
1/4 0.25 2-3/4 6 1 057716
1/4 0.25 2-3/4 6 6 057516
17/64 0.2656 2-7/8 6 6 057517
9/32 0.2812 2-15/16 6 6 057518
19/64 0.2969 3-1/16 6 6 057519
5/16 0.3125 3-3/16 6 1 057720
5/16 0.3125 3-3/16 6 6 057520
21/64 0.3281 3-5/16 6 6 057521
11/32 0.3438 3-7/16 6 6 057522
23/64 0.3594 3-1/2 6 6 057523
3/8 0.375 3-5/8 6 1 057724
3/8 0.375 3-5/8 6 6 057524
7/16 0.4375 4-1/16 6 1 057728
7/16 0.4375 4-1/16 6 6 057528
1/2 0.5 4-1/2 6 1 057732
1/2 0.5 4-1/2 6 6 057532



6" Aircraft Extension - Wire Sizes

SizeDecimal EquivalentFlute LengthOverall LengthPkg QtyPart#
40 0.098 1-3/8 6 6 057640
33 0.113 1-1/2 6 6 057633
30 0.1285 1-5/8 6 6 057630
29 0.136 1-3/4 6 6 057629
27 0.144 1-7/8 6 6 057627
25 0.1495 1-7/8 6 6 057625
21 0.159 2-1/8 6 6 057621
20 0.161 2-1/8 6 6 057620
19 0.166 2-1/8 6 6 057619
18 0.1695 2-1/8 6 6 057618
11 0.191 2-5/16 6 6 057611
10 0.1935 2-7/16 6 6 057610
9 0.196 2-7/16 6 6 057609
6 0.204 2-1/2 6 6 057606
5 0.2055 2-1/2 6 6 057605
2 0.221 2-5/8 6 6 057602



12" Aircraft Extension - Fractional Sizes

SizeDecimal EquivalentFlute LengthOverall LengthPkg QtyPart#
1/16 0.0625 7/8 12 6 058504
5/64 0.0781 1 12 6 058505
3/32 0.0938 1-1/4 12 6 058506
7/64 0.1094 1-1/2 12 6 058507
1/8 0.125 1-5/8 12 1 058408
1/8 0.125 1-5/8 12 6 058508
9/64 0.1406 1-3/4 12 6 058509
5/32 0.1562 2 12 6 058510
11/64 0.1719 2-1/8 12 6 058511
3/16 0.1875 2-5/16 12 1 058412
3/16 0.1875 2-5/16 12 6 058512
13/64 0.2031 2-7/16 12 6 058513
7/32 0.2188 2-1/2 12 6 058514
15/64 0.2344 2-5/8 12 6 058515
1/4 0.25 2-3/4 12 1 058416
1/4 0.25 2-3/4 12 6 058516
17/64 0.2656 2-7/8 12 6 058517
9/32 0.2812 2-15/16 12 6 058518
19/64 0.2969 3-1/16 12 6 058519
5/16 0.3125 3-3/16 12 1 058420
5/16 0.3125 3-3/16 12 3 058520
11/32 0.3438 3-7/16 12 3 058522
3/8 0.375 3-5/8 12 1 058424
3/8 0.375 3-5/8 12 3 058524
13/32 0.4062 3-7/8 12 3 058526
7/16 0.4375 4-1/16 12 1 058428
7/16 0.4375 4-1/16 12 3 058528
15/32 0.4688 4-5/16 12 3 058530
1/2 0.5 4-1/2 12 1 058432
1/2 0.5 4-1/2 12 3 058532



12" Aircraft Extension - Wire Sizes

SizeDecimal EquivalentFlute LengthOverall LengthPkg QtyPart#
1 0.228 2-5/8 12 6 058601
7 0.201 2-7/16 12 6 058607
10 0.1935 2-7/16 12 6 058610
11 0.191 2-5/16 12 6 058611
17 0.173 2-3/16 12 6 058617
20 0.161 2-1/8 12 6 058620
30 0.1285 1-5/8 12 6 058630
40 0.098 1-3/8 12 6 058640
