Roundover Insert Bits


Roundover Insert Router Bits

Designed to round over the top edge of the material. These bits feature a unique capture groove which allows the replaceable inserts to be further recessed into the tool body, allowing for very small cutting diameters.

A single tool body will accept inserts from 1/8" to 3/8" radius.

DescriptionSmall DiameterRadiusShankPart #
Insert Body* 1/2   1/2 8200
Insert Body* 1/2   3/4 8205
Replacement Insert   1/8   INS-8200
Replacement Insert   3/16   INS-8201
Replacement Insert   1/4   INS-8202
Replacement Insert   5/16   INS-8203
Replacement Insert   3/8   INS-8204

 * Insert bodies come complete with inserts. Please specify your choice of inserts when ordering




Round and Rout Insert Router Bits

Designed to round over the top edge of the material and cut out the part at the same time. These bits are designed to cut .010" thru 3/4" material and feature the same unique capture groove which allows the replaceable inserts to be further recessed into the tool body, allowing for very small cutting diameters.

A single tool body will accept inserts from 1/8" to 3/8" radius.

DescriptionSmall DiameterRadiusShankPart #
Insert Body* 1/2   1/2 8210
Insert Body* 1/2   3/4 8211
Replacement Insert   1/8   INS-8211
Replacement Insert   3/16   INS-8212
Replacement Insert   1/4   INS-8213
Replacement Insert   5/16   INS-7830
Replacement Insert   3/8   INS-8214

 * Insert bodies come complete with inserts. Please specify your choice of inserts when ordering

Made in AmericaVortex Tool Company router bits, boring bits and CNC tooling are proudly made in the USA.
